Gerber to CAD

Gerber to GenCAD & AutoCAD & FABmaster

The Problem: CAD Data is not always available or is missing key information needed for Circuit Board Assembly and Test.

Solution: We can convert your Gerber Data to a CAD File  that is complete and fully-functional.

Gerber to CAD Details



Arrow and circuit

Gerber-to-GenCAD

Gencad is  a widely supported "Generic" CAD File Format. Converting gerber to gencad will allow you to completely support  ECAD, Circuit Board Assembly and Test.

Gerber-to-AutoCAD

Gerber to autocad service will import all gerber layers including drill and other document into AutoCAD. We can create unique layers in AutoCAD for each Gerber layer or combine layers. Files can be exported in DXF or DWG.

Gerber to Fabmaster

We convert gerber into a Fully-Functional FabMaster FATF File. This allows you to use all the features in FabMaster to completely support  Circuit Board Assembly and Test.
